Product Description

Part Number	12709880017
Previous Version	1270-988-0017, 1270 988 0017
OE number	04294738, 4294738, 04294738KZ, 20904197
Year	2007-02
Description	Deutz Off Highway, Industrial Engine
CHRA	12707100007 (1270-710-0007) $846.18
Turbo Model	S200G-3071NRAKB0.76DK1
Engine Model	TCD2013
Engine Manufacturer	Deutz
Manufacturer Part Number	12709700017, 1270-970-0017, 1270 970 0017
Displacement	7.15L, 7150 ccm
KW	200/272
Angle α (compressor housing)	21°
Angle β (turbine housing)	356°
Rpm Max	2300
Fuel	Diesel
Bearing Housing	56201500005 $273.90
Turbine Wheel	168431 (Ind. 69. mm, Exd. 55.9 mm, 11 Blades) $476.50 NEW IN STOCK
Comp. Wheel	10771232001 (Milled Alu.)(Ind. 54.61 mm, Exd. 78.61 mm, 7+7 Blades, SuperBack) $200.00 NEW IN STOCK
Back plate	167744 (166537)(1253200300)(304020003) $83.38 NEW IN STOCK
Heat shield Number	167997 $44.74
Repair Kit	318383 (318394) $97.60 NEW IN STOCK
Turbine Housing AR	0.76
Note	Inter cooler
Manufacturer	Borg Warner - 3K - Schwitzer, BWTS UK

Applications

2902-07 Deutz Industrial with TCD2013 Engine

2007- Volvo Industrial with TCD2013 Engine
